Fall Protection Equipment

Key Features

• Ideal for direct connection to most harnesses and can be easily used as a lanyard replacement
• Best suited for situations where an anchor point is available at foot level
• Extremely light in weight, weighing less than 600 gms (excluding hook) for easy user carriage
• High strength polymer casing provides maximum durability
• Has a forged anchorage eye with 360 degree rotation
• Locks quickly; arresting a fall within inches providing more protection at low heights and can also be used horizontally
• Meets the sharp edge test and passes the dynamic test of fall factor 2.
• Fall distance is minimal as compared to energy absorbing lanyards hence retrieval of fall victims is easier

The PCGS device features a durable plastic casing, a secure anchorage handle, and a swivel steel snap hook with a load indicator. It uses galvanized steel wire rope, which retracts or extends as needed. It automatically locks in the event of a fall, limiting the impact to under 6 kN

Key Highlight

• Robust & durable plastic casing.
• Has anchorage handle at anchorage end.
• Swivel steel snap hook with load Indicator our PN 162 at attachment end.
• Galvanized steel wire rope.
• vailable in lengths: 3.5m, 5m, 6m, 7m, 7.5m, 8m, 9m, 10m, 15m, 20m, and 30m.
• Retractable design for easy storage and versatility.
• This retractable fall arrester block features a patented mechanism.

This retractable block are high-performance safety device designed for optimal durability and functionality in challenging environments. Its construction includes a robust and durable plastic casing, which ensures longevity and reliability even in harsh conditions. The retractable block features a handle at the anchorage end, allowing for secure and stable attachment to a fixed point, and facilitating ease of use for the operator.

At the attachment end, the retractable block is equipped with a swivel steel snap hook that includes a load indicator, referenced as PN 162. This feature is critical as it helps users easily monitor the load being applied to the retractable block, ensuring it remains within safe limits. This retractable block is designed with a galvanized steel wire rope, which provides strong resistance to wear and corrosion.

One of the key advantages of this retractable block is its ability to retract or extend to different lengths as required. It maintains a taut configuration with no slack, which prevents tripping hazards and ensures that the user can move freely across various levels. This feature is particularly beneficial in fall hazards environment where mobility and safety are crucial, allowing workers to perform tasks without restriction while remaining securely tethered.

In the event of a fall, the retractable block is equipped with locking mechanism that engages immediately. This ensures that the fall distance is minimized, significantly reducing the risk of injury. The locking mechanism is designed to lower the impact force to less than 6kN, thereby enhancing the safety of the user and providing a critical safeguard against falls.

Overall, these retractable block offers a blend of robust construction, versatile functionality, and advanced safety features. Its ability to provide a secure, retractable connection while allowing for dynamic movement makes it an essential tool for fall protection in various industrial and safety-critical applications.

These retractable blocks are available in the following lengths: 3.5m, 5m, 6m, 7m, 7.5m, 8m, 9m, 10m, 15m, 20m, and 30m.

This block feature a robust plastic casing, stainless steel wire rope, and a swivel steel snap hook with a load indicator. It can be anchored at a single point and allows unrestricted movement at various levels. In case of a fall, it locks immediately, minimizing fall distance and reducing impact force to under 6kN.

Key Highlight

• Robust & durable plastic casing.
• Has anchorage eye at anchorage end.
• Swivel steel snap hook with load Indicator our PN 162 at attachment end.
• Stainless steel wire rope
• This retractable fall arrester block features a patented mechanism.

These retractable blocks is designed for both durability and industrial safety, featuring a robust and durable plastic casing that ensures longevity even under fall hazards. Its design includes an anchorage eye at one end, allowing it to be securely attached to a fixed point. This anchorage setup provides a stable point of attachment while working at height, allowing the user to move freely at various elevations.

The other end of the retractable block is equipped with a swivel steel snap hook, which includes a load indicator. This feature allows for easy and secure connection to various attachment points and provides a clear indication of any load that might be applied, enhancing industrial safety.

The retractable block is constructed with stainless steel wire rope, known for its strength and resistance to corrosion. This ensures that the retractable block remains reliable and effective over time, even in challenging environments. The wire rope's retractable nature allows it to extend or retract as needed, always maintaining a taut line with no slack. This design minimizes the risk of tripping or entanglement and provides the user with the flexibility to move seamlessly.

In the event of a fall, this self retracting lifeline is engineered to lock immediately, which helps to minimize the fall distance and the potential impact force. This quick-locking mechanism is crucial for reducing the risk of injury during a fall, as it ensures that the fall distance is kept to a minimum and that the force experienced is reduced to less than 6kN. This feature provides a high level of safety by effectively managing the forces involved in a fall.

Overall, the retractable block combines robust construction with advanced safety features, making it a reliable choice for users who need to work at height. Its design ensures both security and flexibility, allowing users to perform their tasks with confidence while minimizing risks.

The PN813 Anchorage Steel Wire Rope Sling by KARAM is crafted from 8.0mm galvanized steel wire rope, PVC coated for durability. Featuring steel thimbles at both ends, it provides secure anchorage in industrial environments, particularly around edged structures where high wear resistance is crucial.

Key Highlight

• Constructed from 8.0mm diameter strong galvanized steel wire rope, coated with PVC for enhanced protection.
• Features steel thimbles at both ends as secure attachments for robust and secure anchorage.
• It has versatile applications and is ideal for various industrial settings where reliable anchorage is essential.
• Offers High Wear Resistance, its designed for durability, and is perfect for use around edged structures without compromising strength.

The PN813 Anchorage Steel Wire Rope Sling is an integral part of KARAM's extensive range of Anchorage Wire Rope Slings, specifically designed to meet the demanding requirements of industrial environments. Constructed from 8.0mm diameter galvanized steel wire rope, this sling is exceptionally resistant to wear and tear, making it ideal for use around sharp or edged structures where conventional ropes may fail. The galvanized steel core ensures that the sling can endure heavy loads and harsh conditions, providing reliable performance over extended periods.

What sets the PN813 apart is its PVC coating, which offers an additional layer of protection against corrosion, abrasion, and environmental factors. This coating not only prolongs the life of the sling but also enhances its overall safety by reducing the likelihood of fraying or damage during use. Whether used in construction, manufacturing, or other industrial applications, this wire rope sling is built to withstand the rigors of daily operation, ensuring that safety standards are consistently met.

The sling is equipped with steel thimbles at both ends, providing secure attachment points that are crucial for maintaining the integrity of the anchorage system. These thimbles prevent the rope from being damaged by the metallic contact of connectors, ensuring that the sling remains in optimal condition even after repeated use. The steel thimbles also facilitate easy and quick installation, allowing workers to secure the sling with minimal effort and time.

Designed for versatility, the PN813 can be used in a wide range of applications, from securing scaffolding to anchoring heavy machinery. Its robust construction and reliable performance make it a preferred choice for professionals who prioritize safety and durability in their equipment.

In addition to its practical features, the PN813 Anchorage Steel Wire Rope Sling is lightweight and easy to handle, despite its strong construction. This makes it a convenient tool for workers who need to transport and deploy the sling in various locations. Its compact design also allows for easy storage when not in use, ensuring that it remains in good condition and ready for the next job.
